| BARANG |
MODEL |
AF-1600 |
AF-1800 |
AF-2000 |
| Kemampuan permesinan |
Ayunan di atas tempat tidur |
1600mm |
1800mm |
2000mm |
| Ayunan di atas perosotan silang |
900mm |
1100mm |
1300mm |
| TEMPAT TIDUR |
Lebar |
1400mm |
| Spindel Utama |
hidung spindel |
A2-15 |
| Lubang poros |
230mm |
| Kecepatan spindel (rpm) |
L:10~50, M: 50~150, H: 150~400rpm |
| Bepergian |
Lintas perjalanan (sumbu X) |
900mm |
920mm |
1020mm |
| Perjalanan longitudinal (sumbu Z) |
1500mm |
| Umpan |
Lintasan cepat sumbu X |
5 jt/mnt |
| sumbu Z melintasi cepat |
5 jt/mnt |
| Memotong tingkat umpan |
0,001-500mm/putaran (0,0004"-20"/putaran) |
| Motor |
Motor utama |
motor spindel 1PH8165-1DF00, 37kw |
| inverter |
-------- |
| Motor servo sumbu X |
1FK7101, 4.3kw, 27Nm |
| Motor servo sumbu Z |
1FT7105, 11.7kw, 65Nm |
| Pompa minyak |
30W / 8L |
| Pompa pendingin |
750W, 6~10bar |
| Pompa tangki hidrolik (opsional) |
3hp (2.2kw) |
| Kapasitas Tangki |
Tangki hidrolik (opsional) |
20L |
| Pompa pelumasan |
8L |
| Sekrup bola |
diameter sumbu X |
50mm / Pitch 10 |
| diameter sumbu Z |
80mm / Pitch 10 |
| Tailstock |
Diameter bulu ayam |
--- |
| perjalanan bulu ayam |
--- |
| bulu ayam lancip |
--- |
| Panjang (mm) |
4950mm (dengan konveyor chip: 6610mm) |
| Lebar (mm) |
3100mm |
| Tinggi (mm) |
2750mm |
| BB (kg) |
14600kgs |
