| MODEL |
DY-560M |
DY-660M |
DY-760M |
| MENGAYUN |
Jarak Antar Pusat |
1000/1500/2000/2500/3000/4000/5000/6000 mm |
| Tinggi Tengah (Di Atas Tempat Tidur) |
280 mm |
330 mm |
380 mm |
| Ayunan Di Atas Tempat Tidur |
560 mm |
660 mm |
760 mm |
| Swing Over Cross Slide |
310 mm |
410 mm |
510 mm |
| Swing Over Gap |
800 mm |
900 mm |
1000 mm |
| TEMPAT TIDUR |
Lebar |
410 mm |
| HEADSTOCK |
hidung spindel |
H1-8 / H1-11 (Pilihan) |
| lubang poros |
104 mm / 130 mm (Pengoptimalan) |
| Kecepatan Spindel (rpm) |
25 ~ 1250rpm |
| Jumlah Kecepatan Spindle |
12 Perubahan |
| FEED - BENANG |
leadscrew |
45mm. 2T.PI atau 6 nada |
| Jumlah Perubahan Umpan |
36 |
| Rentang Umpan Membujur |
0,05 ~ 0,70 mm/putaran |
| Rentang Pakan Lintas |
0,025 ~ 0,35 mm/putaran |
| Benang Inci |
2 ~ 28 TPI |
| Benang Metrik |
P0.8 ~ 14 mm |
| DP No. / Rentang |
DP 4 ~ 56 |
| Modul Pitch No. / Rentang |
MOD 0,5 ~ 7 |
| ALAT SLIDE |
Perjalanan Lintas Slide |
380 mm |
| Perjalanan Istirahat Majemuk |
255 mm |
| TAILSTOCK |
Perjalanan Quill |
180 mm |
| Diameter bulu ayam |
75 mm |
| lancip dari pusat |
MT#5 |
| MOTOR |
Motor utama |
15 HP / 20 HP (Pilihan) |
| Motor Umpan Cepat |
1/4HP |
| Pompa Pendingin |
1/8 HP |
| Panjang (mm) |
2800/3300/3800/4300/4800/5800/6800/7800mm |
| Lebar (mm) |
1400 |
| Tinggi (mm) |
1530 |
1630 |
1730 |
| BB (kg) |
2400/2700/3000/3300/3700/4500/5200/6000kg |
