| MODEL |
ATC-600 |
ATC-700 |
ATC-800 |
ATC-900 |
| Kemampuan permesinan |
Jarak Antar Pusat |
1000/1500/2000/3000/4000/5000/6000 mm |
| Ayunan Di Atas Tempat Tidur |
600mm |
700mm |
800mm |
900mm |
| Berayun di atas celah |
900x450 |
1000x450 |
1100x450 |
1200x450 |
| Spindel Utama |
hidung spindel |
D1-8,104mm : L 60~230, M 230~680, H 680~2000rpm |
| lubang poros |
D1-11,130mm : L 40~130, M 130~400, H 400~1200rpm |
| Kecepatan Spindel (rpm) |
A2-11, 165mmz : L 20~110, M 110~320, H 320~660rpm |
| A2-15, 230mm : L 20~110, M 110~320, H 320~660rpm |
| Bepergian |
sumbu X |
460mm |
460mm |
460mm |
460mm |
| Sumbu Y (Opsional) |
+50mm |
+100mm |
+150mm |
+ 150mm |
| sumbu Z |
1020/1520/2020/3020/4020/5020/6020mm |
| Umpan |
Lintasan Cepat Sumbu X |
15M/mnt |
| Lintasan Cepat Sumbu Y (Opsional) |
6 jt/mnt |
| Lintasan Cepat Sumbu Z |
15M/mnt |
| Memotong Tingkat Pakan |
0,001-500mm/putaran (0,0004"-20"/putaran) |
| Motor |
Motor utama |
Motor Spindel 22kw |
| Motor Servo Sumbu X |
Motor Servo AC 3.0kw, 12Nm |
| Motor Servo Sumbu Y (0pt) |
Motor Servo AC 3.0kw, 12Nm, ABS |
| Motor Servo Sumbu Z |
Motor Servo AC 6.0kw, 38Nm |
| Pompa pelumasan |
100 W |
| Pompa Pendingin |
450W, 6~10 bar |
| Pompa Tangki Hidrolik (Opsional) |
5hp (3.7kw) |
| Kapasitas Tangki |
Tangki Hidrolik (Opsional) |
70L |
| Pompa pelumasan |
2L |
| Tangki Pendingin |
100L |
| Sekrup bola |
Diameter Sumbu X |
30mm / nada 10 |
| Diameter sumbu Y |
30mm / nada 10 |
| Diameter Sumbu Z |
50mm / nada 10 |
| Tailstock |
Diameter bulu ayam |
115mm / 160mm (OPT.) |
| Perjalanan Quill |
270mm |
| bulu ayam lancip |
MT6 |
| Panjang (mm) |
3900/4400/4900/5900/6900/7900/8900mm |
| Lebar (mm) |
2300mm |
| Tinggi (mm) |
2300mm |
| BB (kg) |
8500/9500/10500/12000/14000/16000/ 18000 |
